half cut solar panel factory price

Factory customized oem mwt module mono perc half cut solar panel factory price with TUV CE ISO

Order(MOQ):
40HQ
Product Origin:
china
Color:
black
Shipping Port:
shanghai/ningbo
Lead Time：
3days（1—100000w）；5days（10001 —100000w）；1
Weight：
21.8kg
Cell Type:
Mono crystalline
No.of cells:
150 cells
Dimensions:
495w-515w(2187×1102×35mm)；525w-545w(2384×1096×35mm)；535w-555w(2384×1096×35mm)；
Weight:
410w-430w(26.3kg)；525w-545w(28.6kg)；535w-555w(32.3kg)；
Certificate:
CE/TUV/ISO
Payment:
T/T / L/C / Paypal / Western Union
Warranty:
10years

Basic Parameters
Detail Parameters

Factory customized oem mwt module mono perc half cut solar panel factory price with TUV CE ISO

Mono half cell panels, which has high photoelectric conversion efficiency and good stability; The photoelectric conversion efficiency of monocrystalline silicon solar cells is about 15%, and the highest is 24%。

1.Higher Yield Due to Better Shading Response

Half Cell Module comprises two separated and identical solalr cell arrays, which means the ordinary strings of cells are cut into halves, and these shorter strings compose which has separated current paths. When a module is shaded, only one side shaded array's current will be impacted, while the other array will still be functionally producing power. Under this circumstance, when a module is shaded, the affected working areas of Blade will be 50% less.
By cutting solar cell into halves, the internal power loss will be lower and hot spot effect will also be reduced.

2.Less Mismatch Loss

Instead of 6 internal strings of cells, half cell module has 2*6 shorter ones. This design effectively deals with the mismatch
happened between cells caused by shadow, out of sync performance degradation, etc.

A Grade Material：

Glass

* High-transmittance and low reflection
Inspection:GB15763.2-2005.ISO9050
* High solar transmittance
* High mechanical strength

Solar Cell

* High efficiency is 22%
* High shunt-resistance: adapt the several environmental conditions.
* By pass diode minimizes the power drop by shade.
* Excellent low light effect
Low breakage rate

Frame

* Aluminium extrusion profile with prompt delivery.
* Available in customized surface finish.
* Excellent material for smooth and subtle edges.
* Extrusion for construction and other industrial purposes.

Junction Box

* Unique split junction box design to minimize the loss caused by occlusion * Combination of series circuit and parallel circuit, reduced internal power loss. * IP68 Waterproofness, Full-Glue-Filled

Module	SUN495-DE21M	SUN500-DE21M	SUN505-DE21M	SUN510-DE21M	SUN515-DE21M
Maximum Power(Pmax)	495W	500W	505W	510W	515W
Maximum Power Voltage(Vmp)	42.60V	42.80V	43.00V	43.20V	43.40V
Maximum Power Current(Imp)	11.63A	11.69A	11.75A	11.81A	11.87A
Open-circuit Voltage(Voc)	51.50V	51.70V	51.90V	52.10V	52.30V
Short-circuit Current(Isc)	12.21A	12.28A	12.35A	12.42A	12.49A
Module Efficiency STC(%)	20.50%	20.70%	21.00%	21.20%	21.40%
Operating Temperature(℃)	-40℃~+85℃
Maximum system voltage	1500V DC(IEC/UL)
Maximum series fuse rating	20A
Power tolerance	0-+5W
Temperature coefficients of Pmax	-0.340%℃
Temperature coefficients of Voc	-0.250%℃
Temperature coefficients of Isc	0.04%℃
Nominal operating cell temperature(NOCT)	43±2℃

Essential details
Place of Origin:	Anhui, China
Brand Name:	Sunrover Solar
Model Number:	SUN495-515 DE21M(11)
Type:	PERC, Half Cell, Bifacial, Double-glass, Half Cut Solar Panel
Panel Efficiency:	19.50%, 19.70%, 19.90%, 20.20%, 20.40%
Certificate:	ISO/CE/TUV/ETL
Warranty:	10YEARS
Glass:	3.2mm High Tranamission Low Iron
Frame:	Anodized Aluminium Alloy
Junction Box:	Split junction box (IP68, three diode)
Application:	Commercial, civil, open space, roof, lake surface, etc.
OEM/ODM:	Support for solar panel 450 watt stock double glass
Supply Ability	10000 Piece/Pieces per Week solar panel 450 watt stock double glass
Packaging & delivery
Packaging Details	Half cell Mono solar panel from 410w to 670w stock double glass
	1. Standard exporting Wooden and Carton Box
	2. Container: 40'HQ
	3. Pallets Per Container: 22
	4. Pieces Per Container: 660
	The packaging can be customized according to the needs of different customers
Port	Shanghai , China
